| Type: | Clear Quartz Plate | Application: | Semiconductor, optical |
|---|---|---|---|
| Thickness: | 0.5-100mm | Shape: | Mixed |
| Processing Service: | Bending, Welding, Punching, polishing | Product Name: | quartz plate |
| Material: | SIO2>99.99% | Density: | 2.2g/cm3 |
| Working Temparature: | 1150℃ | Hardness: | Morse 6.5 |
| Melt Point: | 1750-1850℃ | Acid tolerance: | 30 times than Ceramics,150 times than stainless steel |
| Size: | Customized | Annealing point: | 1180℃ |
| Strain point: | 1100℃ | Port: | shanghai and Qindao port |
| ハイライト |
卓越した性能のクォーツガラスプレート,電子機器製造 石英ガラスプレート |
||
|
Shengfan石英板の特徴
|
||
| *ブランド | shengfanquartz | |
| *SIO2 | 99.99% | |
| *密度 | 2.2(g/cm³) | |
| *硬度モーススケール | 6.6 | |
| *融点 | 1732℃ | |
| *使用温度 | 1100℃ | |
| *アニーリングポイント | 1180℃ | |
| *軟化点 | 1630℃ | |
| 設定情報 | ||
| 色 | 透明 | |
| 形状 | 混合 | |
| 標準 | JGS1,JGS2,JGS3 | |
| 材質 | 99.99% sio2 | |
| 直径 | 1-800mm | |
| 厚さ | 0.2-100mm | |
| 用途 | 光学石英窓 | |
| 密度 | 6.6 | |
| 光線透過率 | >92% | |
| 硬度 | モース6.5 | |
| 抵抗値 | 通常のガラスの1000倍 | |
カスタマイズ方法
Shengfan石英板の特徴 *ブランド shengfanquartz *SIO2 99.99% *密度 2.2(g/cm³) *硬度モーススケール 6.6 *融点 1732℃ *使用温度 1100℃ *アニーリングポイント 1180℃ *軟化点 1630℃ 設定情報 色 透明 形状 混合 標準 JGS1,JGS2,JGS3 材質 99.99% sio2 直径 1-800mm 厚さ 0.2-100mm 用途 光学石英窓 密度 6.6 光線透過率 >92% 硬度 モース6.5 抵抗値 通常のガラスの1000倍 カスタマイズ方法 1.寸法の図面を作成する 2.図面に基づいて製品を作成する 単位...
Thin Quartz Glass Plate Dimensional Stable 1-1000mm Processing Range Product description: Fused clear silica quartz glass plate is made of high purity quartz sand with excellent thermal shock stability and high transmittance. It is widely used in electric light/ laser/ lenses/optical instrument/high temperature window. Specification Quick Details Place of Origin Jiangsu,China Brand SF Material Glass,High quality Optical Glass Usage Optical Structure Double Convex Shape
Product description: 1.SiO2> 99.99% ,tubing fused quartz 2.Operating Temperature: 1250℃ 3.Excellent visual and chemical performance . 4.Without surface coating andinfectant . 5.Health care and environmental protection. 6.Any specification can be made. 7.Quartz glass is acidic materials, except hydro fluoric acid and 300 degrees Celsius thermal phosphoric acid, on any other acids were shown to be inert, is the best anti acid materials. The advantages of Customized High Quality
No Air Bubble Flat Glass Plates Excellent Visual Performance Circular Shape Quartz Glass Window Product description: Fused clear silica quartz glass plate is made of high purity quartz sand with excellent thermal shock stability and high transmittance. It is widely used in electric light/ laser/ lenses/optical instrument/high temperature window. Application of quartz plate: Military industrial complex, machinery, metallurgy, printing and dyeing, optical instruments, high
Product description: Fused clear silica quartz glass plate is made of high purity quartz sand with excellent thermal shock stability and high transmittance. It is widely used in electric light/ laser/ lenses/optical instrument/high temperature window. Application of quartz plate: Military industrial complex, machinery, metallurgy, printing and dyeing, optical instruments, high temperature sight glasses, fire hole industries such as high temperature and other industries,
